Roll To Roll Pressure Controlled Roller Press Machine MR-DG300-SF is a tiny, less than 6'x6' automatic battery electrode rolling press system with precision digital pressure control. It combines pressure-controlled electric rolling machine with tension-controlled feeding and winding devices to produce electrode rolling and pressing that is completely automatic and up to 75 meters long with a maximum width of 300 mm. It is the ideal instrument for creating prototypes (such as pilot scale research) of new rechargeable battery generations and for rolling electrode sheets under uniform and repeatable circumstances.

*The roller is made of imported cold-rolled chrome molybdenum material by heat-treated surface chrome plating and cryogenic treatment, with high internal and external hardness and good wear resistance;


	220V/110V, 50/60Hz
	Max 25ton
	2 mm
	Max.6m/min adjustable
	Ф200 mm*330mm width
	9Cr3Mo
	HRC65~68
	HRC60-62
	Ra Less than or equal to 0.4
Circular run-out error	＜±2μm

	RT~150 degree


	±1.5μm


	1400mm L X 500mm W X 1300mm H
	2KW
	0.5-0.8MPa compressed air
	About 600KG
	It is recommended that the ambient temperature is 25 ± 3 degree , the humidity is 30 ~ 90rh, and there is no vibration and electromagnetic interference
	The reduction of lithium electrode piece is 20% ~ 30% at a time. If it is thinner, it needs to be rolled several times (5μm/ time)
